Vîndut
Descriere
Placa de Baza ASROCK B850M-X AM5, 2x DDR5, 1x HDMI 1x DP, 2x PCIE 4.0 x16 1x PCIE 4.0 x1, 3x M.2, 4x SATA 6GB/s, mATX
Livrare
Informații suplimentare
| PCI |
0 |
|---|---|
| Serial-or-Paralel |
No/No |
| Video-Connection |
HDMI/DP |
| Wi-FI |
No |
| Onboard-CPU |
No |
| RAID support |
Yes |
| Component for |
PC |
| DisplayPort version |
1.4 |
| USB connector type |
USB Type-A, USB Type-C |
| Memory channels |
Dual-channel |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Maximum internal memory |
128 GB |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| Processor manufacturer |
AMD |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| Audio output channels |
7.1 channels |
| Line-in |
Yes |
| Audio Chip |
Realtek ALC897 |
| Number of memory slots |
2 |
| Supported storage drive types |
HDD & SSD |
| Number of M.2 (M) slots |
2 |
| Maximum resolution |
3840 x 2160 pixels |
| PCI Express x16 (Gen 4.x) slots |
2 |
| HDCP |
Yes |
| Screws included |
Yes |
| DisplayPorts quantity |
1 |
| VGA (D-Sub) ports quantity |
0 |
| Parallel processing technology support |
Not supported |
| DVI-D ports quantity |
0 |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Model Chipset |
B850 |
| Gaming |
Nu |
| Soclu Procesor |
Socket AM5 |
| Tip Memorie: |
DDR5 |
| Numar sloturi memorie |
2 |
| Memorie maxima |
128 GB |
| Tip slot interfata grafica |
PCIe 4.0 x16 |
| Chipset audio integrat |
Realtek |
| Canale audio |
7.1 |
| Wireless |
Nu |
| Bluetooth |
Nu |
| USB Type-C |
Da |
| HDMI |
Da |
| Thunderbolt |
Nu |
| Sloturi M.2 |
3 |
| RJ-45 LAN |
1 |
| Memory slots type |
DIMM |
| Unbuffered memory |
Yes |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0 |
| Number of SATA III connectors |
4 |
| Front panel audio connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| CPU fan connector |
Yes |
| EPS power connector (8-pin) |
Yes |
| Motherboard form factor |
micro ATX |
| Motherboard chipset family |
AMD |
| BIOS type |
UEFI AMI |
| BIOS memory size |
256 Mbit |
| Supported memory types |
DDR5-SDRAM |
| ECC сompatibility |
ECC & Non-ECC |
| Number of CPU fan connectors |
2 |
| TPM connector |
Yes |
| RGB LED pin header |
Yes |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| 1st M.2 highest PCI Express generation |
5.0 |
| 2nd M.2 highest PCI Express generation |
4.0 |
| 12V power connector |
Yes |
| Number of storage drives supported |
6 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| RAID levels |
0, 1, 10 |
| Processor socket |
Socket AM5 |
| Supported processor sockets |
Socket AM5 |
| Compatible processor series |
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Supported storage drive interfaces |
PCI Express 4.0, PCI Express 5.0, SATA III |
| Number of chassis fan connectors |
3 |
| Number of RGB LED pin headers |
1 |
| LAN controller |
Dragon RTL8125BG |
| Motherboard chipset |
AMD B850 |
| 1st M.2 largest key size |
2280 |
| 2nd M.2 largest key size |
2280 |
| PCI Express x1 (Gen 4.x) slots |
1 |
| Number of EPS power connectors (8-pin) |
1 |
| Microphone in |
Yes |
| Product colour |
Black |
| Ethernet LAN (RJ-45) ports |
1 |
| Cables included |
SATA |
| Width |
244 mm |
| Headphone outputs |
3 |
| Certification |
FCC, CE, ErP/EuP |
| Depth |
226 mm |
| Format |
Micro-ATX |
| Producator |
ASROCK |
| Garantie |
