Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch,
14,978.75 lei
Stoc epuizat
Report Abuse
Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch, 48 x 10/100/1000BASE-T ports, 2 x 10GBASE-T and 4 x 10G SFP+ ports, Layer 3, 80 Gbps.
| Stackable |
Yes |
|---|---|
| LAN-Port-Type |
Gigabit |
| Storage relative humidity (H-H) |
5 – 90% |
| Password protection |
Yes |
| Jumbo frames support |
Yes |
| Link aggregation |
Yes |
| USB 2.0 ports quantity |
1 |
| Pallet gross width |
120 cm |
| Number of fans |
2 fan(s) |
| Pallet gross length |
110 cm |
| Rack mounting |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| System event log |
Yes |
| Switch type |
Managed |
| 10G support |
Yes |
| Port mirroring |
Yes |
| DoS attack prevention |
Yes |
| Access Control List (ACL) |
Yes |
| Power over Ethernet (PoE) |
No |
| Fiber optic connector |
SFP |
| Flow control support |
Yes |
| IGMP snooping |
Yes |
| Redundant power supply (RPS) support |
Yes |
| Installed SFP modules quantity |
0 |
| Master (outer) cases per pallet (air) |
48 pc(s) |
| Broadcast storm control |
Yes |
| Spanning tree protocol |
Yes |
| MAC address table |
16384 entries |
| Number of queues |
8 |
| Multicast support |
Yes |
| Switch layer |
L3 |
| Number of VLANs |
4000 |
| SSH/SSL support |
Yes |
| Loop protection |
Yes |
| Authentication |
Guest VLAN, MAC-based authentication, Port-based authentication |
| GARP VLAN Registration Protocol (GVRP) |
Yes |
| Basic switching RJ-45 Ethernet ports type |
48 |
| ARP inspection |
Yes |
| Switching capacity |
216 Gbit/s |
| Forwarding rate |
161 Mpps |
| BPDU filtering/protection |
Yes |
| Packet buffer memory |
4 MB |
| Power connector |
AC-in jack |
| Head-of-line (HOL) blocking |
Yes |
| Queue scheduling algorithms |
SP, WRR+SP, Weighted Round Robin (WRR) |
| Multicast features |
Controllable multicast |
| Virtual stacking (units) |
32 |
| Access Control List (ACL) egress |
512 |
| Access Control List (ACL) ingress |
2048 |
| Routing protocols |
RIP |
| Physical stacking (units) |
9 |
| Pallet height (air) |
197.5 cm |
| Pallet height (sea) |
197.5 cm |
| Copper ethernet cabling technology |
10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Security algorithms |
SNMP, SNMPv3, SSH-2, SSL/TLS |
| Virtual LAN features |
Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN |
| DHCP features |
DHCP server, DHCP snooping, DHCP relay, DHCP client |
| Root protection |
Yes |
| Virtual Router Redundancy Protocol (VRRP) |
Yes |
| Safety |
CB, cUL, BSMI, CCC |
| Telnet |
Yes |
| sFlow |
Yes |
| Mean time between failures (MTBF) |
478258 h |
| Heat dissipation |
172.72 BTU/h |
| Shipping (inner) case height |
46 cm |
| Shipping (inner) case width |
19.8 cm |
| Shipping (inner) case length |
52.4 cm |
| Shipping (inner) case net weight |
9.66 kg |
| Pallet gross weight (air) |
522.6 kg |
| Products per pallet (air) |
96 pc(s) |
| Pallet gross weight (sea) |
522.6 kg |
| Products per pallet (sea) |
96 pc(s) |
| Shipping (inner) case gross weight |
10.5 kg |
| I/O ports |
2 x 10GBASE-T |
| Porturi RJ 45 |
28+ |
| Viteza Transfer |
10G+ |
| Porturi SFP |
3-4 |
| Montare in Rack |
Da |
| SFP module slots quantity |
4 |
| Management |
Da |
| PoE |
Nu |
| Product colour |
Black, Grey |
| Operating relative humidity (H-H) |
10 – 90% |
| Harmonized System (HS) code |
85176990 |
| Operating temperature (T-T) |
0 – 50 °C |
| Storage temperature (T-T) |
-40 – 70 °C |
| LED indicators |
Yes |
| Package height |
70 mm |
| AC input voltage |
100 – 240 V |
| Width |
440 mm |
| Height |
44 mm |
| Package weight |
4.83 kg |
| Products per shipping (inner) case |
2 pc(s) |
| Depth |
290 mm |
| Package width |
427 mm |
| Certification |
FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC |
| Noise level |
51.9 dB |
| Power consumption (max) |
50.62 W |
| Weight |
3.72 kg |
| Package depth |
506 mm |
| Producator |
D-LINK |
