"JetStream™ 24-Port SFP L2+ Managed Switch with 4 10GE SFP+
Prețul inițial a fost: 5,984.00 lei.3,776.00 leiPrețul curent este: 3,776.00 lei.
3 în stoc
Report Abuse
„JetStream™ 24-Port SFP L2+ Managed Switch with 4 10GE SFP+ Slots PORT: 20× Gigabit SFP Ports, 4× Gigabit SFP/RJ45 Combo Ports, 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with JetStream™ SDN Controller, Static Routing, OAM, sFlow, DDM, 802.1Q VLAN, QinQ, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6, Dual Redundant Power Supplies”
| Layer |
Layer-2 |
|---|---|
| Stackable |
No |
| Rackable |
Yes |
| LAN-Port-Type |
Gigabit |
| Redundant-PSU |
Yes |
| Storage relative humidity (H-H) |
5 – 90% |
| Password protection |
Yes |
| Jumbo frames support |
Yes |
| Link aggregation |
Yes |
| Number of fans |
1 fan(s) |
| Power supply included |
Yes |
| Ethernet LAN data rates |
10,100,1000,10000 Mbit/s |
| Rack mounting |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Static route |
Yes |
| Web-based management |
Yes |
| System event log |
Yes |
| Switch type |
Managed |
| 10G support |
Yes |
| Port mirroring |
Yes |
| Form factor |
1U |
| Policy-based routing |
Yes |
| MAC address filtering |
Yes |
| Access Control List (ACL) |
Yes |
| Power over Ethernet (PoE) |
No |
| Switch layer |
L2 |
| Flow control support |
Yes |
| Rate limiting |
Yes |
| IGMP snooping |
Yes |
| Redundant power supply (RPS) support |
Yes |
| IGMP proxy |
Yes |
| Rack mount kit |
Yes |
| Configuring Location Settings (CLI) |
Yes |
| Broadcast storm control |
Yes |
| Spanning tree protocol |
Yes |
| Multicast support |
Yes |
| Jumbo frames |
9000 |
| Active link detection |
Yes |
| IP routing |
Yes |
| Number of VLANs |
4000 |
| MAC address table |
16000 entries |
| Switching capacity |
128 Gbit/s |
| SSH/SSL support |
Yes |
| Loop protection |
Yes |
| GARP VLAN Registration Protocol (GVRP) |
Yes |
| ARP inspection |
Yes |
| BPDU filtering/protection |
Yes |
| Store-and-forward |
Yes |
| Power connector |
AC-in jack |
| Combo SFP ports quantity |
4 |
| Packet buffer memory |
12 MB |
| Head-of-line (HOL) blocking |
Yes |
| Console port |
RJ-45/micro-USB |
| Number of static routes |
48 |
| IP-MAC-Port binding |
Yes |
| Queue scheduling algorithms |
SP, WRR+SP, Weighted Round Robin (WRR) |
| Multicast Listener Discovery (MLD) snooping |
Y |
| Management protocols |
SNMPv1/v2c/v3, SNTP |
| Authentication type |
AAA, RADIUS, TACACS+ |
| Basic switching RJ-45 Ethernet ports type |
No |
| IPv4 routes |
48 |
| IPv6 routes |
48 |
| DHCP features |
DHCP client, DHCP relay, DHCP server |
| Authentication |
Auto VLAN, Guest VLAN, MAC-based authentication, Port-based authentication |
| IPv4 & IPv6 features |
IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Number of power supply units |
2 |
| Forwarding rate |
95.23 Mpps |
| MIB support |
RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925 |
| Fiber ports quantity |
20 |
| Fiber optic connector |
SFP, SFP+ |
| Routing entries |
512 |
| Virtual LAN features |
Port-based VLAN, Private VLAN, Tagged VLAN, VLAN mapping, Voice VLAN |
| Heat dissipation |
121.81 BTU/h |
| Porturi RJ 45 |
1-4 |
| Viteza Transfer |
10G+ |
| Porturi SFP |
3-4 |
| Montare in Rack |
Da |
| SFP module slots quantity |
4 |
| LAN Ports |
24 |
| Management |
Da |
| PoE |
Nu |
| Product colour |
Black |
| Cables included |
AC |
| Operating relative humidity (H-H) |
10 – 90% |
| Operating temperature (T-T) |
0 – 45 °C |
| Storage temperature (T-T) |
-40 – 70 °C |
| Manual |
Yes |
| LED indicators |
Yes |
| Package height |
100 mm |
| Depth |
220 mm |
| Power source |
AC |
| Package weight |
2.97 kg |
| Cloud-managed |
Yes |
| Width |
440 mm |
| Height |
44 mm |
| Package width |
528 mm |
| Power consumption (max) |
35.7 W |
| Package depth |
336 mm |
| Producator |
TP-LINK |
