"JetStream™ 16-Port Gigabit Smart Switch with 8-Port PoE+ PORT:
1,992.00 lei
Stoc epuizat
Report Abuse
„JetStream™ 16-Port Gigabit Smart Switch with 8-Port PoE+ PORT: 8× Gigabit PoE+ Ports SPEC: 802.3af/at, 120 W PoE Power, Desktop Steel Case FEATURE: Integration with JetStream™ SDN Controller, Static Routing, 802.1Q VLAN, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image, IPv6”
| Layer |
Layer-2 |
|---|---|
| Stackable |
No |
| Rackable |
No |
| LAN-Port-Type |
Gigabit |
| Redundant-PSU |
No |
| LAN Ports |
16 |
| Storage relative humidity (H-H) |
5 – 90% |
| Jumbo frames support |
Yes |
| Link aggregation |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Power over Ethernet (PoE) |
Yes |
| Rack mounting |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| System event log |
Yes |
| Switch type |
Managed |
| Port mirroring |
Yes |
| Firmware upgradeable |
Yes |
| MAC address filtering |
Yes |
| Access Control List (ACL) |
Yes |
| Power connector |
DC-in jack |
| Auto MDI/MDI-X |
Yes |
| Flow control support |
Yes |
| Rate limiting |
Yes |
| IGMP snooping |
Yes |
| IPv4 & IPv6 features |
Dual stack IPv4/IPv6 |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Auto-negotiation |
Yes |
| Installed SFP modules quantity |
0 |
| Configuring Location Settings (CLI) |
Yes |
| 10G support |
No |
| Broadcast storm control |
Yes |
| Spanning tree protocol |
Yes |
| Number of queues |
8 |
| Multicast support |
Yes |
| Basic switching RJ-45 Ethernet ports type |
16 |
| MAC address table |
8000 entries |
| Jumbo frames |
9000 |
| Switching capacity |
32 Gbit/s |
| Fanless |
Yes |
| Number of VLANs |
4000 |
| SSH/SSL support |
Yes |
| Authentication |
Guest VLAN, MAC-based authentication, Port-based authentication |
| GARP VLAN Registration Protocol (GVRP) |
Yes |
| ARP inspection |
Yes |
| Packet buffer memory |
4.1 MB |
| BPDU filtering/protection |
Yes |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| MAC address entries |
Dynamic MAC address entries, Static MAC address entries |
| IP-MAC-Port binding |
Yes |
| Multicast Listener Discovery (MLD) snooping |
MLD v1, MLD v2 |
| DC input voltage |
53.5 V |
| Switch layer |
L2/L2+ |
| Total Power over Ethernet (PoE) budget |
120 W |
| Virtual LAN features |
Multicast VLAN, Tagged VLAN, Voice VLAN |
| Queue scheduling algorithms |
SP, Weighted Round Robin (WRR) |
| Forwarding rate |
23.81 Mpps |
| MIB support |
RFC1213, RFC1493, RFC2674, RFC2620, RFC2618, RFC2925, RFC1757 |
| DHCP features |
DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| Security algorithms |
EAP-MD5, HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSL/TLS |
| Supported network protocols |
ICMP, TCPv6, UDPv6, Ping6, Tracert6, Telnet (v6), TFTP, TCP/UDP, DSCP/IP, SSLv3, TLS 1.2 |
| Heat dissipation |
499.98 BTU/h |
| Porturi RJ 45 |
11-18 |
| Viteza Transfer |
Gigabit |
| Porturi SFP |
N/A |
| Montare in Rack |
Nu |
| Management |
Da |
| PoE |
Da |
| Operating temperature (T-T) |
0 – 40 °C |
| Cables included |
AC |
| Operating relative humidity (H-H) |
10 – 90% |
| Storage temperature (T-T) |
-40 – 70 °C |
| Height |
25.4 mm |
| Cloud-managed |
Yes |
| Power source |
DC/PoE |
| Width |
286 mm |
| Depth |
111.7 mm |
| LED indicators |
PoE, Power, System |
| Power consumption (max) |
146.5 W |
| Producator |
TP-LINK |
| Garantie |
