IP-COM PRO-S8-150W, 8 x 10/100/1000 Base-T Ethernet ports(PoE), 1 x
1,128.77 lei
Stoc epuizat
Report Abuse
IP-COM PRO-S8-150W, 8 x 10/100/1000 Base-T Ethernet ports(PoE), 1 x 10/100/1000 Base-T Ethernet port(data), 1 x 1000 Base-X SFP port, Standards&Protocols: IEEE802.3、IEEE802.3u、IEEE802.3ab、IEEE802.3z、 IEEE802.3x、IEEE802.3af/at、IEEE802.1p、IEEE802.1q、IEEE802.1w、IEEE802. 1d、 IEEE802.1s, Switching capacity: 20 Gbps, 1 X RJ45 Console port, Packet forwarding rate: 14.9 Mpps, VLAN Layer-3 interfaces.
| LAN-Port-Type |
Gigabit |
|---|---|
| Storage relative humidity (H-H) |
5 – 90% |
| Link aggregation |
Yes |
| Power over Ethernet (PoE) |
Yes |
| Rack mounting |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Static route |
Yes |
| Web-based management |
Yes |
| Switch type |
Managed |
| Port mirroring |
Yes |
| Form factor |
1U |
| Access Control List (ACL) |
Yes |
| Power over Ethernet (PoE) ports quantity |
8 |
| IGMP snooping |
Yes |
| Basic switching RJ-45 Ethernet ports type |
9 |
| Installed SFP modules quantity |
0 |
| 10G support |
No |
| Spanning tree protocol |
Yes |
| Multicast support |
Yes |
| IP routing |
Yes |
| MAC address table |
16000 entries |
| Packet buffer memory |
1.5 MB |
| Loop protection |
Yes |
| ARP inspection |
Yes |
| Switching capacity |
20 Gbit/s |
| BPDU filtering/protection |
Yes |
| Power over Ethernet (PoE) power per port |
30 W |
| Store-and-forward |
Yes |
| MAC address auto-learning supported |
Yes |
| Total Power over Ethernet (PoE) budget |
130 W |
| Security algorithms |
SNMP, SNMPv2, SNMPv3 |
| Forwarding rate |
14.9 Mpps |
| DHCP features |
DHCP Option 82, DHCP relay, DHCP server, DHCP snooping |
| Queue scheduling algorithms |
SP, Weighted Round Robin (WRR) |
| Porturi RJ 45 |
5-10 |
| Viteza Transfer |
Gigabit |
| Porturi SFP |
1-2 |
| Montare in Rack |
Da |
| SFP module slots quantity |
1 |
| Switch layer |
L2/L3 |
| Management |
Da |
| PoE |
Da |
| Operating relative humidity (H-H) |
10 – 90% |
| Product colour |
Grey |
| Operating temperature (T-T) |
0 – 45 °C |
| Storage temperature (T-T) |
-40 – 70 °C |
| LED indicators |
Yes |
| Power source |
AC |
| Compliance certificates |
CE, RoHS |
| AC input voltage |
100 – 240 V |
| Certification |
FCC, CE, RoHS |
| Height |
44 mm |
| Depth |
179.6 mm |
| Width |
294 mm |
| Producator |
IP-COM |
| Garantie |
