Name: Sursa MSI MAG A550BN, 80 PLUS Bronze, 550 W
SKU: MAG A550BN
Availability: OutOfStock

Descriere

Sursa MSI MAG A550BN 80+ Bronze SPECIFICATIONS Product Name MAG A550BN PSU Form Factor ATX Power Watt 550W Input Voltage 100-240Vac Input Current 115Vac/8.0A max. 230Vac/4.0A max. Input Frequency 50Hz ~ 60Hz Efficiency Up to 85% (80 Plus Bronze) Fan Size 120 mm Dimension 150mm x140mm x86mm PFC Type Active PFC Protection OCP / OVP / OPP / OTP / SCP https://www.msi.com/Power-Supply/MAG-A550BN/Specification

Livrare

Informații suplimentare

PSU Type	ATX
Number of fans	1 fan(s)
Purpose	PC
80 PLUS certification	80 PLUS Bronze
Fan diameter	12 cm
Conectivitate:	Non Modular
Iluminare RGB	Nu
Certificare 80 Plus	80 PLUS Bronze
Combined power (+5Vsb)	12.5 W
Max output current (+5Vsb)	2.5 A
Motherboard power connector	20+4 pin ATX
EPS power connector (4+4 pin)	Yes
CPU power connector (4+4 pin)	Yes
Cabling type	Non-Modular
Power supply unit (PSU) form factor	ATX
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit
Motherboard power cable length	60 cm
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	110 W
Max output current (+3.3V)	20 A
Max output current (+5V)	20 A
Combined power (+5V)	110 W
Peripheral (Molex) power connectors (4-pin)	2
Number of SATA power connectors	5
EPS power connector (8-pin)	No
PCI Express power connectors (6+2 pin)	2
ATX Power connector (24-pin)	No
Total power	550 W
Maximum input current (@110V)	8 A
Maximum input current (@220V)	4 A
ATX power connector (20+4 pin)	No
Combined power (-12V)	546 W
Max output current (-12V)	45.5 A
PSU Power	550 W
PFC	Active
Width	150 mm
Harmonized System (HS) code	84733020
Height	86 mm
On/off switch	Yes
AC input voltage	100 – 240 V
Depth	140 mm
Producator	MSI
Garantie	120
