Descriere

Sursa ASUS ROG LOKI 1000W 80+Platinum Intel Form Factor SFX-L ATX 3.0 Yes Dimensions 125 x 125 x 63.5 mm Efficiency 80Plus Platinum Protection Features OPP/OVP/UVP/SCP/OCP/OTP Hazardous Materials ROHS AC Input Range 100-240Vac DC Output Voltage +3.3V +5V +12V -12V +5Vsb Maximum Load 20A 20A 83.3A 0.8A 2.5A Combined Load 110W 110W 1000W 9.6W 12.5W Total Output 1000W Connectors MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 PCI-E 8-pin x 3 SATA x 6 PERIPHERAL x 4

Livrare

Informații suplimentare

Number of fans	1 fan(s)
Purpose	PC
80 PLUS certification	80 PLUS Platinum
Illumination	Yes
Fan diameter	12 cm
Peripheral (Molex) power connectors (4-pin)	4
PSU Type	SFX-L
Conectivitate:	Full – Modular
Iluminare RGB	Da
Certificare 80 Plus	80 PLUS Platinum
Efficiency	80Plus-Platinum
Modular	Yes
Combined power (+5Vsb)	12.5 W
Max output current (+5Vsb)	2.5 A
Number of SATA power connectors	6
CPU power connector (4+4 pin)	Yes
Motherboard power connector	24-pin ATX
Cabling type	Fully-Modular
Combined power (+3.3V)	110 W
Max output current (+3.3V)	20 A
Max output current (+5V)	20 A
Combined power (+5V)	110 W
PCI Express power connectors (6+2 pin)	3
Supported motherboard form factors	ATX
Total power	1000 W
Max output current (-12V)	83.3 A
Combined power (-12V)	1000 W
Power supply unit (PSU) form factor	SFX-L
PSU Power	1000 W
PFC	Active
Product colour	Black, Silver
Weight	1.83 kg
Compliance certificates	RoHS
Depth	125 mm
Package type	Box
Package height	100 mm
Width	125 mm
Package weight	2.52 kg
AC input voltage	100 – 240 V
Silent mode	Yes
Height	63.5 mm
Package depth	190 mm
Package width	285 mm
Certification	OPP/OVP/UVP/SCP/OCP/OTP
Producator	ASUS
Garantie	120
