Descriere

Mechanical Hardware PoE LEDs Dimensions 210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14″) Weight 610 g (1.34 lb) Enclosure material Polycarbonate Total non-blocking throughput 9 Gbps Switching capacity 18 Gbps Forwarding rate 13.392 Mpps Networking interface (8) 10/100/1000 MbE RJ45 ports (1) 1G SFP port Managementinterface Ethernetin-band Bluetooth BLE Power method External AC/DC adapter Power supply 27VDC, 4.4A power adapter (included) Supported voltage range 24 – 28VDC Max. power consumption 8W (excludes PoE output) ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV Operating temperature -10 to 50° C (14 to 122° F) Operating humidity 5 to 95% non-condensing Certications CE, FCC, IC PoE interface (8) 27V passive PoE: 2-pair (pins 4, 5+/7, 😎 or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 😎 Max. Passive PoE wattage per port 30W/27VDC Passive PoE voltage range 27VDC System Status RJ45 data ports PoE Speed/link/activity SFP data ports Link/activity

Livrare

Informații suplimentare

Additional-Slot	No
Wireless-Router	No
Rackable	No
LAN-Port-Type	Gigabit
LAN Ports	8
Redundant-PSU	No
Ethernet LAN data rates	10,100,1000 Mbit/s
Power over Ethernet (PoE)	Yes
Switch type	Managed
Power connector	DC-in jack
Power over Ethernet (PoE) ports quantity	8
Switch layer	L2
Basic switching RJ-45 Ethernet ports type	8
Fiber uplink ports quantity	1
Fiber optic connector	SFP
DC input voltage	20 – 28 V
Input current	4.4 A
Power over Ethernet (PoE) type supported	Passive PoE
Segment	Consumer
Viteza Transfer	10/100/1000 Mbps
Porturi RJ 45	Peste 5
Port USB	Nu
Montare in Rack	Nu
PoE	Da
SFP module slots quantity	1
Quick start guide	Yes
User guide	Yes
Product colour	White
Operating temperature (T-T)	-10 – 50 °C
Operating relative humidity (H-H)	5 – 95%
Depth	95 mm
Manual	Yes
Housing material	Polycarbonate (PC)
Height	29 mm
Power source	DC
Certification	CE, FCC, IC
Power consumption (typical)	8 W
Width	210.4 mm
Weight	610 g
LED indicators	LAN, Power, WAN, WLAN
Producator	UBIQUITI
Garantie	24
