Placa de baza Gigabyte B550M DS3H AC, Socket AM4, DDR4,

Name: Placa de baza Gigabyte B550M DS3H AC, Socket AM4, DDR4,
SKU: B550M DS3H AC
Availability: OutOfStock

839.34 lei

Stoc epuizat

Adaugă la favorite

SKU: B550M DS3H AC Categorie: Placi de baza

Descriere

Placa de baza Gigabyte B550M DS3H AC AM4 DDR4, 4x sloturi RAM, max. 128GB, frecventa maxima suportata 4733MHz, 1x DVI-D, 1x HDMI, 2x PCIe x16, 1x PCIe x1, 2x M.2, 4x conectori SATA 6GB/s, 1x LAN 1Gbps, WIFI, Bluetooth 4.2, microATX

Livrare

Informații suplimentare

PCI	0
Serial-or-Paralel	No/No
Video-Connection	DVI/HDMI
Wi-FI	Yes
Onboard-CPU	No
RAID support	Yes
Component for	PC
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
DisplayPort version	1.4
USB connector type	USB Type-A
Ethernet interface type	Gigabit Ethernet
Memory channels	Dual-channel
Ethernet LAN	Yes
HDMI ports quantity	1
HDMI version	2.1
Maximum internal memory	128 GB
WLAN controller model	Realtek RTL8821CE
Processor manufacturer	AMD
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
PCI Express x16 (Gen 3.x) slots	1
Audio output channels	7.1 channels
PCI Express x1 (Gen 3.x) slots	1
Line-in	Yes
PCI Express x16 slots	1
Audio Chip	Realtek ALC897
PCI Express x16 (Gen 4.x) slots	1
On-board graphics card	No
Supported storage drive types	HDD & SSD
Supported memory types	DDR4-SDRAM
LAN controller	Realtek RTL8111H
Number of M.2 (M) slots	2
Processor socket	Socket AM4
Cooling type	Passive
Motherboard chipset	AMD B550
PCI Express x1 slots	1
HDCP	Yes
Screws included	Yes
DVI-D ports quantity	1
DisplayPorts quantity	1
VGA (D-Sub) ports quantity	0
Parallel processing technology support	Not supported
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Model Chipset	B550
Gaming	Nu
Soclu Procesor	Socket AM4
Tip Memorie:	DDR4
Numar sloturi memorie	4
Memorie maxima	128 GB
Tip slot interfata grafica	PCIe 3.0 x16
Chipset audio integrat	Realtek
Canale audio	7.1
Wireless	Da
USB Type-C	Da
HDMI	Da
Thunderbolt	Nu
Sloturi M.2	2
RJ-45 LAN	1
Number of memory slots	4
Memory slots type	DIMM
Unbuffered memory	Yes
Supported storage drive interfaces	M.2, SATA III
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of SATA III connectors	4
Number of SATA II connectors	0
Number of SATA connectors	0
Front panel audio connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
Number of chassis fan connectors	2
EPS power connector (8-pin)	Yes
PS/2 ports quantity	1
Motherboard form factor	micro ATX
Motherboard chipset family	AMD
BIOS type	UEFI AMI
Clear CMOS jumper	Yes
mSATA ports quantity	0
ECC сompatibility	ECC & Non-ECC
Number of HDDs supported	4
Front panel connector	Yes
TPM connector	Yes
Number of water pump connectors	2
RGB LED pin header	Yes
WiFi-AP antenna jack	2
ACPI version	5.0
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Lithium weight per battery	0.07 g
Antenna included	Yes
Total number of SATA connectors	4
12V power connector	Yes
Number of storage drives supported	6
BIOS memory size	128 Mbit
Serial port headers	1
RAID levels	0, 1, 10
PCI Express x4 slots	1
2nd M.2 largest key size	2280
USB 2.0 connectors	1
PC health monitoring	Fan, Temperature, Voltage
Number of EPS power connectors (8-pin)	1
Supported processor sockets	Socket AM4
Maximum internal memory supported by processor	128 GB
Audio connector	Yes
Supported memory module capacities	4GB, 8GB, 16GB, 32GB
Number of CPU fan connectors	1
1st M.2 highest PCI Express generation	4.0
Power fan connector	Yes
Parallel connector	Yes
1st M.2 largest key size	22110
Number of RGB LED pin headers	5
Number of Parallel ATA connectors	1
Digital audio optical out	3
Maximum internal memory per slot	32 GB
Bundled software	Norton Internet Security LAN bandwidth management software
Compatible operating systems	Windows 10 64-bit
Compatible processor series	AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series
2nd M.2 highest PCI Express generation	3.0
Supported memory clock speeds	4733,4600,4400,4266,4133,4000,3866,3733,3600,3466,3400,3200,2933,2667,2400,2133 MHz
Microphone in	Yes
Headphone outputs	1
Bluetooth	Yes
Bluetooth version	4.2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Batteries included	Yes
Ethernet LAN (RJ-45) ports	1
Height	35 mm
Width	244 mm
Warranty period	3 year(s)
Country of origin	China
Package height	68 mm
Power source type	ATX
Battery weight	3 g
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Product colour	Brown
Products per shipping (inner) case	1 pc(s)
Package width	270 mm
Package depth	268 mm
Package weight	10.9 kg
Depth	24.4 mm
Format	Micro-ATX
Producator	GIGABYTE
Garantie	36
