Name: Placa de baza ASUS TUF GAMING B550-PLUS WIFI II, Socket
SKU: TUF B550-PLUS WI 2
Availability: OutOfStock

Placa de baza ASUS TUF GAMING B550-PLUS WIFI II, Socket

1,388.42 lei

Stoc epuizat

SKU: TUF B550-PLUS WI 2 Categorie: Placi de baza

Descriere

Placa de baza Asus TUF B550-PLUS WIFI II AM4 DDR4

Livrare

Informații suplimentare

PCI	0
Serial-or-Paralel	No/No
Video-Connection	HDMI/DP
Wi-FI	Yes
USB3	4-8
PCI-Ex1	1
Onboard-CPU	No
RAID support	Yes
Component for	PC
Windows operating systems supported	Windows 10, Windows 11
USB connector type	USB Type-A, USB Type-C
Memory channels	Dual-channel
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Ethernet LAN	Yes
HDMI ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
Maximum internal memory	128 GB
Processor manufacturer	AMD
USB 2.0 ports quantity	2
USB4 Gen 3x2 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
PCI Express x16 (Gen 3.x) slots	1
Audio output channels	7.1 channels
Line-in	Yes
PCI Express x16 (Gen 4.x) slots	1
On-board graphics card	No
Supported storage drive types	HDD & SSD
Supported memory types	DDR4-SDRAM
Number of M.2 (M) slots	2
Processor socket	Socket AM4
S/PDIF out port	Yes
Motherboard chipset	AMD B550
USB 3.2 Gen 2x2 Type-C ports quantity	0
DisplayPorts quantity	1
VGA (D-Sub) ports quantity	0
USB4 Gen 2x2 ports quantity	0
Parallel processing technology support	Not supported
DVI-D ports quantity	0
DVI-I ports quantity	0
Drivers included	Yes
Model Chipset	B550
Gaming	Da
Format	ATX
Soclu Procesor	Socket AM4
Tip Memorie:	DDR4
Numar sloturi memorie	4
Memorie maxima	128 GB
Tip slot interfata grafica	PCIe 4.0 x16
Chipset audio integrat	Realtek
Canale audio	7.1
Wireless	Da
Bluetooth	Da
USB Type-C	Da
HDMI	Da
Thunderbolt	Nu
Sloturi M.2	2
RJ-45 LAN	1
Compatible processor series	AMD Ryzen 3000 Series
Number of memory slots	4
Memory slots type	DIMM
Unbuffered memory	Yes
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of SATA II connectors	0
Number of SATA connectors	0
Front panel audio connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
EPS power connector (8-pin)	Yes
Motherboard chipset family	AMD
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
mSATA ports quantity	0
TPM connector	Yes
RGB LED pin header	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Motherboard form factor	ATX
Number of COM connectors	1
Thunderbolt headers	1
PS/2 ports quantity	0
PCI Express x1 slots	0
PCI Express x1 (Gen 2.x) slots	0
PCI Express x1 (Gen 4.x) slots	0
PCI Express x4 slots	0
PCI Express x4 (Gen 1.x) slots	0
PCI Express x4 (Gen 2.x) slots	0
PCI Express x4 (Gen 4.x) slots	0
PCI Express x8 slots	0
PCI Express x8 (Gen 1.x) slots	0
PCI Express x16 slots	0
PCI Express x16 (Gen 2.x) slots	0
PCI Express x16 (Gen 3.x) @ dual x8/x8 mode slots	0
PCI slots	0
PCI-X slots	0
Mini PCI Express slots	0
Mini PCI Express (Gen 1.x) slots	0
Mini PCI Express (Gen 2.x) slots	0
Mini PCI Express slot (full length)	0
Mini PCI Express slot (half-length)	0
RAID levels	0, 1, 10
Number of SATA III connectors	6
Number of chassis fan connectors	3
PCI Express x1 (Gen 3.x) slots	3
Supported processor sockets	Socket AM4
Number of displays supported	2
ECC сompatibility	ECC
Supported storage drive interfaces	M.2, SATA
USB 3.2 Gen 2x2 connectors	0
PCI Express x16 (Gen 5.x) slots	0
PCI Express OCuLink connectors (NVMe support)	0
MB-Format	ATX
RAM-Slots	4
MB-Socket	AM4
PCI-Ex16	2
Microphone in	Yes
Headphone outputs	1
Bluetooth version	5.2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Weight	945 g
Harmonized System (HS) code	84733020
Cables included	SATA
Height	7.5 mm
Width	30.5 mm
Depth	24.4 mm
Producator	ASUS
Garantie	36
