TUF Gaming B550M-PLUS distileaza elemente esentiale ale celei mai recente platforme AMD si le combina cu caracteristici gata de joc si durabilitate dovedita. Proiectata cu componente de calitate militara, o solutie de putere modernizata si un set cuprinzator de optiuni de racire, aceasta placa de baza ofera performante solide si stabilitate de joc neclintita.
| PCI |
0 |
|---|---|
| Serial-or-Paralel |
No/No |
| Video-Connection |
HDMI/DP |
| Wi-FI |
No |
| CPU încorporat |
No |
| Windows operating systems supported |
Windows 10 x64 |
| Memory channels |
Dual-channel |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| Maximum internal memory |
128 GB |
| Processor manufacturer |
AMD |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| PCI Express x16 (Gen 3.x) slots |
1 |
| Audio output channels |
7.1 channels |
| LAN controller |
Realtek RTL8125B |
| PCI Express x16 (Gen 4.x) slots |
1 |
| Supported memory types |
DDR4-SDRAM |
| Number of M.2 (M) slots |
2 |
| Processor socket |
Socket AM4 |
| S/PDIF out port |
Yes |
| Motherboard chipset |
AMD B550 |
| DisplayPorts quantity |
1 |
| VGA (D-Sub) ports quantity |
0 |
| DVI-D ports quantity |
0 |
| Drivers included |
Yes |
| Model Chipset |
B550 |
| Gaming |
Da |
| Format |
ATX |
| Soclu Procesor |
Socket AM4 |
| Tip Memorie: |
DDR4 |
| Numar sloturi memorie |
4 |
| Memorie maxima |
128 GB |
| Tip slot interfata grafica |
N/A |
| Chipset audio integrat |
Realtek |
| Canale audio |
7.1 |
| Wireless |
Nu |
| Bluetooth |
Nu |
| USB Type-C |
Da |
| HDMI |
Da |
| Thunderbolt |
Nu |
| Sloturi M.2 |
2 |
| RJ-45 LAN |
1 |
| Compatible processor series |
AMD Ryzen 3000 Series |
| Number of memory slots |
4 |
| Memory slots type |
DIMM |
| Supported memory clock speeds |
2133,2400,2666,2800,3000,3200,3333,3466,3600,3733,3866,4000,4133,4266,4400,4600 MHz |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1 |
| Front panel audio connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| CPU fan connector |
Yes |
| EPS power connector (8-pin) |
Yes |
| PS/2 ports quantity |
1 |
| Motherboard chipset family |
AMD |
| BIOS type |
UEFI AMI |
| BIOS memory size |
256 Mbit |
| Clear CMOS jumper |
Yes |
| TPM connector |
Yes |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Motherboard form factor |
ATX |
| Maximum number of SMP processors |
1 |
| RAID levels |
0, 1, 10 |
| Parallel processing technology support |
2-Way CrossFireX |
| Number of SATA III connectors |
6 |
| Firewire (IEEE 1394) ports |
0 |
| Number of chassis fan connectors |
3 |
| PCI Express x1 (Gen 3.x) slots |
3 |
| Supported processor sockets |
Socket AM4 |
| Number of SATA connectors |
4 |
| ECC сompatibility |
ECC |
| Supported storage drive interfaces |
M.2, SATA |
| Component for |
Nettop |
| Audio Chip |
Realtek ALC S1200A |
| Ethernet LAN (RJ-45) ports |
1 |
| Weight |
945 g |
| Harmonized System (HS) code |
84733020 |
| Cables included |
SATA |
| Height |
6.8 mm |
| Width |
30.5 mm |
| Depth |
24.4 mm |
| Producator |
ASUS |
| Garantie |
