Placa de bază ASRock X670E AM5
2,174.66 lei
Stoc epuizat
Report Abuse
Placa de baza AsRock Socket AM5, X670E PG Lightning Supports AMD Ryzen™ 7000 Series Processors 14+2+1 Phase Power Design, SPS 4 x DDR5 DIMMs, supports up to 6600+(OC) 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 PCIe 4.0 x16, 1 PCIe 4.0 x1, 1 M.2 Key-E for WiFi Graphics Output Options: 1 HDMI, 1 DisplayPort 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio 1 Blazing M.2 (PCIe Gen5x4), 1 Hyper M.2 (PCIe Gen4x4), 1 Ultra M.2 (PCIe Gen3x4 & SATA3), 1 M.2 (PCIe Gen4x2), 4 SATA3 1 USB 3.2 Gen2 Type-A (Rear), 10 USB 3.2 Gen1 (6 Rear, 4 Front), 8 USB 2.0 (4 Rear, 4 Front) Realtek 2.5G LAN
| PCI |
0 |
|---|---|
| Serial-or-Paralel |
No/No |
| Video-Connection |
HDMI/DP |
| Wi-FI |
No |
| Onboard-CPU |
No |
| RAID support |
Yes |
| Component for |
PC |
| DisplayPort version |
1.4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| Memory channels |
Dual-channel |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
1 |
| Maximum internal memory |
128 GB |
| Processor manufacturer |
AMD |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| USB 2.0 ports quantity |
4 |
| Audio output channels |
7.1 channels |
| Line-in |
Yes |
| Audio Chip |
Realtek ALC897 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
| DisplayPorts quantity |
1 |
| VGA (D-Sub) ports quantity |
0 |
| DVI-D ports quantity |
0 |
| Model Chipset |
X670E |
| Gaming |
Nu |
| Format |
ATX |
| Soclu Procesor |
Socket AM5 |
| Tip Memorie: |
DDR5 |
| Numar sloturi memorie |
4 |
| Memorie maxima |
128 GB |
| Tip slot interfata grafica |
PCIe 5.0 x16 |
| Chipset audio integrat |
Realtek |
| Canale audio |
7.1 |
| Wireless |
Nu |
| Bluetooth |
Nu |
| USB Type-C |
Da |
| HDMI |
Da |
| Thunderbolt |
Nu |
| Sloturi M.2 |
4 |
| RJ-45 LAN |
1 |
| Number of memory slots |
4 |
| Memory slots type |
DIMM |
| USB 2.0 connectors |
2 |
| Number of SATA III connectors |
4 |
| Front panel audio connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| CPU fan connector |
Yes |
| EPS power connector (8-pin) |
Yes |
| Motherboard chipset family |
AMD |
| BIOS memory size |
256 Mbit |
| Supported memory types |
DDR5-SDRAM |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
1 |
| TPM connector |
Yes |
| RGB LED pin header |
Yes |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Motherboard form factor |
ATX |
| Windows operating systems supported |
Windows 11 x64 |
| ECC сompatibility |
Non-ECC |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| RAID levels |
0, 1, 10 |
| Processor socket |
Socket AM5 |
| Motherboard chipset |
AMD X670 |
| PCI Express x4 slots |
1 |
| LAN controller |
Realtek RTL8125-BG |
| Compatible processor series |
AMD Ryzen™ 7 |
| BIOS type |
EFI AMI |
| Supported storage drive interfaces |
M.2, NVMe, SATA III |
| Microphone in |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Cables included |
SATA |
| Width |
30.5 mm |
| Depth |
24.4 mm |
| Producator |
ASROCK |
| Garantie |
