UPS APC Smart-UPS SRT online dubla-conversie 8000VA / 8000W 6

Name: UPS APC Smart-UPS SRT online dubla-conversie 8000VA / 8000W 6
SKU: SRT8KRMXLI
Availability: OutOfStock

Prețul inițial a fost: 59,949.33 lei.Prețul curent este: 48,841.28 lei.

Stoc epuizat

Adaugă la favorite

SKU: SRT8KRMXLI Categorie: UPS

Descriere

APC Smart-UPS SRT 8000VA RM 230V

High density, double-conversion on-line power protection with scalable runtime

Includes: CD with software, Documentation CD, Installation guide, Rack mounting brackets, Rack mounting hardware, Rack mounting support rails, Temperature probe, USB cable, Warranty card, Web/SNMP management card

Max. Capacity Used

—

Please enter load to see calculated „Max. Capacity Used”

100%

Output power capacity

8.0kWatts / 8.0kVA

Rack Height

Output Connections

(4) IEC 60320 C19 (Battery Backup)

(4) IEC 320 C19 (Battery Backup)

(6) IEC 60320 C13 (Battery Backup)

(6) IEC 320 C13 (Battery Backup)

(1) Hard Wire 3-wire (H N + G) (Battery Backup)

(3) IEC Jumpers (Battery Backup)

Nominal Output Voltage

230V

Nominal Input Voltage

230V, 400V 3PH

Input Connections

Hard wire 3-wire (1P + N + E), Hard wire 5-wire (3P + N + E)

Output Voltage Distortion

Less than 2 %

Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz Sync to mains

Other Output Voltages

220, 240

Load Crest Factor

3 : 1

Topology

Double conversion online

Waveform type

Sine wave

Bypass

Internal bypass (automatic and manual)

Livrare

Informații suplimentare

Culoare	Negru
Rackable	Yes
USB Port	Yes
Capacitate putere UPS	8000W
Quick installation guide	Yes
Operating altitude	0 – 3000 m
Storage relative humidity (H-H)	0 – 95%
Temperature sensor	Yes
Rack mount kit	Yes
Surge protection	Yes
Audible alarm(s)	Yes
Tip UPS:	Online
Capacitate Rack:	6U
Ecran LCD:	Da
Port USB	Da
Number of output phases	1
Serial interface	Yes
Waveform	Sine
Output frequency regulation	50/60 Hz
Hot-swap battery	Yes
Automatic battery test	Yes
Cold start	Yes
Non-operating altitude	0 – 15000 m
Output operation voltage (min)	220 V
Output operation voltage (max)	240 V
Emergency Power Off (EPO)	Yes
AC outlet types	C13 coupler, C19 coupler
Form factor	Rackmount/Tower
Auto-restart	Yes
SmartSlot	Yes
UPS topology	Double-conversion (Online)
Input operation voltage (min)	100 V
Input frequency	40 – 70 Hz
Surge energy rating	480 J
Crest factor	3:1
Power plug	Hardwire
AC outlets quantity	10 AC outlet(s)
Serial interface type	RJ-45
Bracket	Yes
Output voltage Total Harmonic Distortion (THD)	3%
Output power capacity	8 kVA
Rack capacity	6U
Input operation voltage (max)	476 V
Number of output IEC jumpers	3
Output power	8000 W
Efficiency	94.8%
Battery capacity	1728 VAh
Typical backup time at full load	5.2 min
Typical backup time at half load	14.5 min
Total carbon footprint (kg of CO2e)	18632.76
Protectie supratensiune	Da
UPS-Management	Yes
Display	Da
Operating temperature (T-T)	0 – 40 °C
Software CD	Yes
Battery technology	Sealed Lead Acid (VRLA)
Operating relative humidity (H-H)	0 – 95%
Warranty card	Yes
Width	71.5 mm
Harmonized System (HS) code	85078000
Display type	LCD
LED indicators	Status
Battery recharge time	1.5 h
Battery life (max)	5 year(s)
Storage temperature (T-T)	-15 – 45 °C
Cables included	USB cable
Noise level	55 dB
Package width	600 mm
Certification	REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Packaging content	Web/SNMP Management Card
Package depth	1000 mm
Height	2.63 mm
Package height	461 mm
Weight	111.8 kg
Package weight	130 kg
Products per pallet	1 pc(s)
Depth	43.2 mm
Numar baterii	2
Tip:	Online
Alarme sonore	Da
IEC C13	6
Tensiune de alimentare	230V
Baterie	Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
Baterie inlocuitoare	APCRBC140
Timp incarcare	1.5 ore
IEC C19	4
Interfata	RJ-45 SerialSerial RJ-45Smart-SlotUSB
Montare in Rack	Da6U
Dimensiuni	263 x 432 x 715 mm
Greutate	111.82 kg
Altii	Hard Wire 3 wire (H N + G) 3x IEC Jumpers
Putere	8000 VA
Capacitate baterie	1728 VAh
Incarcare	8 kW
Timp mediu de functionare	14.5 minute
Altele	Montare in rack: 6U
Producator	APC
Garantie	36
